(3pcs) P2103ABL Littelfuse Sidactor Sym 3Chp 170V 100A To220A
Tax included.
THIS LISTING IS FOR (3PCS) OF P2103ABL BY LITTELFUSE/TECCOR
Mfr Package Description MODIFIED TO-220, 3 PIN
EU RoHS Compliant Yes
Status Active
Trigger Device Type THYRISTOR SURGE PROTECTOR
Breakover Voltage-Min 180.0 V
Breakover Voltage-Max 240.0 V
Configuration STAR CONNECTED, 3 ELEMENTS
DC Off-state Voltage-Max 170.0 V
Holding Current-Max 150.0 mA
JESD-30 Code R-PSIP-T3
JESD-609 Code e3
Moisture Sensitivity Level 1
Non-Repetitive Pk On-state Cur 25.0 A
Number of Elements 3.0
Number of Terminals 3
Operating Temperature-Min -40.0 Cel
Operating Temperature-Max 150.0 Cel
Package Body Material PLASTIC/EPOXY
Package Shape RECTANGULAR
Package Style IN-LINE
Peak Reflow Temperature (Cel) 260
Qualification Status Not Qualified
Reference Standard UL RECOGNIZED
Sub Category Silicon Surge Protectors
Surface Mount NO
Terminal Finish MATTE TIN
Terminal Form THROUGH-HOLE
Terminal Position SINGLE
Time@Peak Reflow Temperature-Max (s) 30
