(2PCS) ADM485AN ANALOG DEVICES Single Transeiver RS-422/RS-485 8-Pin PDIP
Tax included.
THIS LISTING IS FOR (2PCS) OF ADM485AN BY ANALOG DEVICES
SPECIFICATIONS
| Mfr Package Description | MO-095AA, PLASTIC, DIP-8 |
| REACH Compliant | Yes |
| Status | EOL |
| Interface IC Type | LINE TRANSCEIVER |
| Differential Output | YES |
| Driver Number of Bits | 1.0 |
| High Level Input Current-Max | 1.0E-6 Amp |
| Input Characteristics | DIFFERENTIAL SCHMITT TRIGGER |
| Interface Standard | EIA-422; EIA-485 |
| JESD-30 Code | R-PDIP-T8 |
| JESD-609 Code | e0 |
| Moisture Sensitivity Level | NOT APPLICABLE |
| Number of Functions | 1 |
| Number of Terminals | 8 |
| Operating Temperature-Min | -40.0 Cel |
| Operating Temperature-Max | 85.0 Cel |
| Out Swing-Min | 1.5 V |
| Output Characteristics | 3-STATE |
| Output Low Current-Max | 0.004 Amp |
| Output Polarity | COMPLEMENTARY |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | DIP |
| Package Equivalence Code | DIP8,.3 |
| Package Shape | RECTANGULAR |
| Package Style | IN-LINE |
| Peak Reflow Temperature (Cel) | NOT APPLICABLE |
| Power Supplies (V) | 5 |
| Qualification Status | Not Qualified |
| Receive Delay-Max | 40.0 ns |
| Receiver Number of Bits | 1.0 |
| Seated Height-Max | 4.57 mm |
| Sub Category | Line Driver or Receivers |
| Supply Current-Max | 2.2 mA |
| Supply Voltage-Nom | 5.0 V |
| Supply Voltage-Min | 4.75 V |
| Supply Voltage-Max | 5.25 V |
| Surface Mount | NO |
| Technology | BICMOS |
| Temperature Grade | INDUSTRIAL |
| Terminal Finish | Tin/Lead (Sn85Pb15) |
| Terminal Form | THROUGH-HOLE |
| Terminal Pitch | 2.54 mm |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | NOT APPLICABLE |
| Transmit Delay-Max | 15.0 ns |
| Length | 9.27 mm |
| Width | 7.62 mm |
| Additional Feature | 1 RECEIVER ACTIVE UNDER SHUTDOWN; COMMON I/O; TRISTATABLE RECEIVERS |
