(3000 PCS) PMSTA92 PHILIPS TRANS PNP 300V 0.1A SOT323 ROHS
Tax included.
THIS IS FOR (3000 PCS) OF PMSTA92 BY PHILIPS
TRANS PNP 300V 0.1A SOT323 ROHS
Manufacturer: (PHILIPS) Nexperia
Product Category: Bipolar Transistors - BJT
RoHS: YES
Mounting Style: SMD/SMT
Package / Case: SOT-323-3
Transistor Polarity: PNP
Configuration: Single
Collector- Emitter Voltage VCEO Max: 300 V
Collector- Base Voltage VCBO: 300 V
Emitter- Base Voltage VEBO: 5 V
Collector-Emitter Saturation Voltage: 250 mV
Maximum DC Collector Current: 100 mA
Pd - Power Dissipation: 200 mW
Gain Bandwidth Product fT: 50 MHz
Minimum Operating Temperature: - 65 C
Maximum Operating Temperature: + 150 C
Qualification: AEC-Q101
Packaging: Reel
Packaging: Cut Tape
Brand: Nexperia
DC Collector/Base Gain hfe Min: 40 at 1 mA, 10 V, 40 at 10 mA, 10 V, 30 at 30 mA, 10 V
DC Current Gain hFE Max: 40 at 1 mA, 10 V
Height: 1 mm
Length: 2.2 mm
Product Type: BJTs - Bipolar Transistors
3000
Subcategory: Transistors
Technology: Si
Width: 1.35 mm
Part # Aliases: 934042290115
Unit Weight: 0.000176 oz
