(300 PCS) 1N5239B-T DIODES INC ZENER DIODE 500mW 9.1V DO-35
Tax included.
THIS LISTING IS FOR (300 PCS) OF 1N5239B-T BY DIODES INC
ZENER DIODE 500mW 9.1V DO-35
ZENER DIODE 500mW 9.1V DO-35
1N5239B-T Part Details & Parametric
| EU RoHS |
Compliant
|
| Configuration | Single |
| Nominal Zener Voltage (V) | 9.1 |
| Maximum Reverse Leakage Current (uA) | 3 |
| Maximum Zener Impedance (Ohm) | 10 |
| Maximum Power Dissipation (mW) | 500 |
| Packaging | Tape and Reel |
| Test Current (mA) | 20 |
| Zener Voltage Tolerance | 5% |
| Minimum Operating Temperature (°C) | -65 |
| Maximum Operating Temperature (°C) | 200 |
| Package Diameter (mm) | 2(Max) |
| Mounting | Through Hole |
| Package Length (mm) | 4(Max) |
| PCB | 2 |
| Standard Package Name | DO-204-AH |
| Supplier Package | DO-35 |
| Pin Count | 2 |
| Lead Shape | Through Hole |
