EU RoHS
Compliant
-
Maximum Rate of Rise of Off-State Voltage (V/us)
650(Min)
-
Maximum Rate of Rise of On-State Current (A/us)
175
-
Maximum Gate Trigger Voltage (V)
1.5
-
Maximum Gate Trigger Current (mA)
65
-
Surge Current Rating (A)
520
-
Maximum Holding Current (mA)
200
-
Repetitive Peak Reverse Voltage (V)
400
-
Peak On-State Voltage (V)
2.2@80A
-
Repetitive Peak Forward Blocking Voltage (V)
400
-
Rated Average On-State Current (A)
25
-
RMS On-State Current (A)
40
-
Repetitive Peak Off-State Current (mA)
0.01
-
Phase Control
No
-
Minimum Operating Temperature (°C)
-40
-
Maximum Operating Temperature (°C)
125
-
Mounting
Surface Mount
-
Package Height (mm)
4.78(Max)
-
Package Length (mm)
10.67(Max)
-
Package Width (mm)
9.4(Max)
-
PCB changed
2
-
Tab
Tab
-
Standard Package Name
TO-263
-
Supplier Package
D2PAK
-
Pin Count
3
