(2PCS) RTE24012 General Purpose Relays DPDT 8 A 12VDC
Tax included.
THIS LISTING IS FOR (2PCS) OF RTE24012 BY TYCO/SCHRACK
| Product: | Power Relays | |
| Type: | Slim Form | |
| Contact Termination: | Solder Pin | |
| Mounting Style: | Through Hole | |
| Contact Form: | DPDT (2 Form C) | |
| Contact Current Rating: | 8 A | |
| Switching Voltage: | 250 VAC | |
| Coil Voltage: | 12 VDC | |
| Coil Termination: | Solder Pin | |
| Coil Type: | Non-Latching | |
| Coil Resistance: | 360 Ohms | |
| Coil Current: | 33.3 mA | |
| Contact Material: | Silver Nickel | |
| Height: | 15.7 mm | |
| Length: | 29 mm | |
| Maximum Switching Current: | 15 A | |
| Packaging: | Tube | |
| Power Consumption: | 400 mW |
