| EU RoHS |
Compliant with Exemption
|
| ECCN (US) |
EAR99 |
| Type |
Trimmer |
| Resistance Value (Ohm) |
100K |
| Tolerance |
10% |
| Maximum Voltage Rating (V) |
300 |
| Power Rating (W) |
0.25 (1/4) |
| Technology |
Cermet |
| Minimum Operating Temperature (°C) |
-55 |
| Maximum Operating Temperature (°C) |
125 |
| Temperature Coefficient (ppm/°C) |
±100 |
| Linear or Logarithmic |
Lin |
| Termination Style |
Pin |
| Positions of Adjustment |
Top |
| Shaft Diameter (mm) |
1.78 |
| Number of Turns (Turns) |
12(Elec) |
| Number of Elements |
1 |
| Electrical Rotation (°) |
4320 |
| Mechanical Rotational Life (Cycles) |
200 |
| Packaging |
Tube |
| Product Length (mm) |
6.71 |
| Product Depth (mm) |
4.5 |
| Product Height (mm) |
8.26 |
| Product Weight (g) |
0.425 |
| Mounting |
Through Hole |
