(25PCS) ZXT849KTC ZETEX Bipolar (BJT) Transistor NPN 30V 7A 100MHz 4.2W TO-252-3
Tax included.
THIS IS FOR (25 PCS) OF ZXT849KTC BY ZETEX
Bipolar (BJT) Transistor NPN 30V 7A 100MHz 4.2W TO-252-3
Part #: ZXT849KTC
Part Category: Transistors
Manufacturer: (ZETEX) DIODES Incorporated
Description: Power Bipolar Transistor, 7A I(C), 30V V(BR)CEO, 1-Element, NPN, Silicon, Plastic/Epoxy, 2 Pin
Mfr Package Description DPAK-3
Status Transferred
Case Connection COLLECTOR
Collector Current-Max (IC) 7.0 A
Collector-emitter Voltage-Max 30.0 V
Configuration SINGLE
DC Current Gain-Min (hFE) 40.0
JESD-30 Code R-PSSO-G2
JESD-609 Code e3
Moisture Sensitivity Level 1
Number of Elements 1.0
Number of Terminals 2
Package Body Material PLASTIC/EPOXY
Package Shape RECTANGULAR
Package Style SMALL OUTLINE
Peak Reflow Temperature (Cel) 260
Polarity/Channel Type NPN
Qualification Status Not Qualified
Surface Mount YES
Terminal Finish Matte Tin (Sn)
Terminal Form GULL WING
Terminal Position SINGLE
Time@Peak Reflow Temperature-Max (s) 40
Transistor Application SWITCHING
Transistor Element Material SILICON
Transition Frequency-Nom (fT) 100.0 MHz
