(25PCS) SN74HCT02D TI NOR Gate, HCT Series, 4-Func, 2-Input, CMOS, SOIC14 HCT02

$7.95
Unit price per

Tax included.

This listing is for (25PCS) of SN74HCT02D by Texas Instruments

Status Discontinued

Family HCT

JESD-30 Code R-PDSO-G14

J-STD-609 Code e4

Length (mm) 8.6500

Load Capacitance (pF) 50.0000

Logic IC Type NOR GATE

Output Low Current-Max (mA) 4.000000000000000

Moisture Sensitivity Level 1

Number of Functions 4

Number of Inputs 2

Number of Terminals 14

Operating Temperature-Max (Cel) 85

Operating Temperature-Min (Cel) -40

Package Body Material PLASTIC/EPOXY

Package Code SOP

Package Equivalence Code SOP14,.25

Package Shape RECTANGULAR

Package Style SMALL OUTLINE

Packing Method TUBE

Peak Reflow Temperature (Cel) 260

Supply Current-Max (mA) 0.02000000

Propagation Delay-Max@Nom-Sup (ns) 25.000000000000000000

Propagation Delay (ns) 25.0000

DLA Qualification Not Qualified

Schmitt Trigger NO

Seated Height-Max (mm) 1.7500

Supply Voltage-Max (V) 5.5000

Supply Voltage-Min (V) 4.5000

Supply Voltage-Nom (V) 5

Surface Mount YES

Technology CMOS

Temperature Grade INDUSTRIAL

Terminal Finish NICKEL PALLADIUM GOLD

Terminal Form GULL WING

Terminal Pitch (mm) 1.270

Terminal Position DUAL

Time@Peak Reflow Temperature-Max (s) 30

Width (mm) 3.9000
