(25PCS) NPI43C4R7MTRF General Purpose Inductor 4.7uH 20% 1 Element SMD 1816 ROHS

$4.95
Unit price per

Tax included.

THIS IS FOR (25 PCS) OF NPI43C4R7MTRF BY NIC

General Purpose Inductor 4.7uH 20% 1 Element SMD 1816 ROHS

Part #: NPI43C4R7MTRF

Part Category: Inductors

Manufacturer: NIC Components Corp.

Description: General Purpose Inductor, 4.7uH, 20%, 1 Element, SMD, 1816

Mfr Package Description CHIP

REACH Compliant Yes

EU RoHS Compliant Yes

China RoHS Compliant Yes

Status Active

Inductor Type GENERAL PURPOSE INDUCTOR

Case/Size Code 1816

Construction Rectangular

DC Resistance 0.08 ohm

Inductance-Nom (L) 4.7 µH

Inductor Application POWER INDUCTOR

JESD-609 Code e3

Number of Functions 1

Number of Terminals 2

Operating Temperature-Min -40.0 Cel

Operating Temperature-Max 125.0 Cel

Package Height 3.2 mm

Package Length 4.5 mm

Package Width 4.0 mm

Packing Method TR, 13 Inch

Rated Current-Max 1.9 A

Shape/Size Description RECTANGULAR PACKAGE

Shielded NO

Surface Mount YES

Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier

Terminal Placement DUAL ENDED

Terminal Shape ONE SURFACE

Test Frequency 0.1 MHz

Tolerance 20.0 %
