(25PCS) 1N4006 DIODE 800V 1A DO41
Tax included.
THIS LISTING IS FOR (10PCS) OF 1N4006 BY DIODES INC.
DIODE GENERAL PURPOSE 800V 1A DO41
1N4006 Part Details & Parametric
|
|
|
| Minimum Operating Temperature (°C) | -65 |
| Maximum Operating Temperature (°C) | 150 |
| Type | Switching Diode |
| Peak Reverse Current (uA) | 5 |
| Configuration | Single |
| Packaging | Tape and Reel |
| Peak Reverse Repetitive Voltage (V) | 800 |
| Maximum Continuous Forward Current (A) | 1@Ta=75C |
| Peak Forward Voltage (V) | 1 |
| Peak Non-Repetitive Surge Current (A) | 30 |
| Operating Junction Temperature (°C) | -65 to 150 |
| Package Diameter (mm) | 2.71(Max) |
| Mounting | Through Hole |
| Package Length (mm) | 4.7(Max) |
| PCB | 2 |
| Standard Package Name | DO-204-AL |
| Supplier Package | DO-41 |
| Pin Count | 2 |
| Lead Shape | Through Hole |
