(25PC) HD74LS194AP Shift Register Single 4-Bit Serial/Parallel to Parallel 16PIN
Tax included.
THIS LISTING IS FOR (5 PCS) OF HD74LS194AP BY HITACHI
Shift Register Single 4-Bit Serial/Parallel to Parallel 16PIN
Part #: HD74LS194AP
Part Category: Logic ICs
Manufacturer: Hitachi, Ltd.
Description: Parallel In Parallel Out, LS Series, 4-Bit, Bidirectional, True Output, TTL, PDIP16
Mfr Package Description DP-16
Status Transferred
Logic IC Type PARALLEL IN PARALLEL OUT
Sub Category Shift Registers
Count Direction BIDIRECTIONAL
Family LS
fmax-Min 25.0 MHz
JESD-30 Code R-PDIP-T16
Max Frequency@Nom-Sup 2.5E7 Hz
Number of Bits 4
Number of Functions 1
Number of Terminals 16
Operating Temperature-Min -20.0 Cel
Operating Temperature-Max 75.0 Cel
Output Polarity TRUE
Package Body Material PLASTIC/EPOXY
Package Code DIP
Package Equivalence Code DIP16,.3
Package Shape RECTANGULAR
Package Style IN-LINE
Propagation Delay (tpd) 26.0 ns
Qualification Status Not Qualified
Seated Height-Max 5.06 mm
Supply Voltage-Nom (Vsup) 5
Surface Mount NO
Technology TTL
Temperature Grade COMMERCIAL EXTENDED
Terminal Form THROUGH-HOLE
Terminal Pitch 2.54 mm
Terminal Position DUAL
Trigger Type POSITIVE EDGE
Length 19.2 mm
Width 7.62 mm
