(25 PCS) ZXMP3A17E6TA DIODES INC Trans MOSFET P-CH 30V 4A 6-Pin SOT-23 T/R ROHS
Tax included.
THIS LISTING IS FOR (25 PCS) OF ZXMP3A17E6TA BY DIODES INC
Trans MOSFET P-CH 30V 4A 6-Pin SOT-23 T/R ROHS
Manufacturer: Diodes Incorporated
Product Category: MOSFET
RoHS: YES
Technology: Si
Mounting Style: SMD/SMT
Package / Case: SOT-26-6
Transistor Polarity: P-Channel
Number of Channels: 1 Channel
Vds - Drain-Source Breakdown Voltage: 30 V
Id - Continuous Drain Current: 4 A
Rds On - Drain-Source Resistance: 70 mOhms
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Vgs th - Gate-Source Threshold Voltage: 1 V
Qg - Gate Charge: 15.8 nC
Minimum Operating Temperature: - 55 C
Maximum Operating Temperature: + 150 C
Pd - Power Dissipation: 1.7 W
Channel Mode: Enhancement
Packaging: Cut Tape
Packaging: Reel
Configuration: Single
Height: 1.3 mm
Length: 3.1 mm
Product: MOSFET Small Signal
Series: ZXMP3A
Transistor Type: 1 P-Channel
Type: MOSFET
Width: 1.8 mm
Brand: Diodes Incorporated
Forward Transconductance - Min: 6.4 S
Fall Time: 8.72 ns
Product Type: MOSFET
Rise Time: 2.87 ns
Factory Pack Quantity: 3000
Subcategory: MOSFETs
Typical Turn-Off Delay Time: 29.2 ns
Typical Turn-On Delay Time: 1.74 ns
Unit Weight: 0.000282 oz
