(25 PCS) X68C64SI XICOR EEPROM, 8KX8, 120ns, Parallel, CMOS, SOIC-24
Tax included.
THIS IS FOR (25 PCS) OF X68C64SI BY XICOR
EEPROM, 8KX8, 120ns, Parallel, CMOS, SOIC-24
Part #: X68C64SIT1
Obsolete
Part Category:EEPROMs
Manufacturer:XICOR INC
Description:
EEPROM, 8KX8, 120ns, Parallel, CMOS, PDSO24
Status Discontinued
Access Time-Max (ns) 120.0000000000000000
Additional Feature 100K ENDURANCE WRITE CYCLES; DATA RETENTION 100 YEARS
Data Retention Time-Min 100
Endurance (Write/Erase Cycles) 100000.000000000000000
JESD-30 Code R-PDSO-G24
Length (mm) 15.4000
Memory Density (bits) 65536.0000000000000000
Memory IC Type EEPROM
Memory Width 8
Number of Functions 1
Number of Terminals 24
Number of Words (words) 8192.0000000000000000
Number of Words Code 8K
Operating Mode ASYNCHRONOUS
Operating Temperature-Max (Cel) 85.0
Operating Temperature-Min (Cel) -40.0
Memory Organization 8KX8
Output Characteristics 3-STATE
Package Body Material PLASTIC/EPOXY
Package Code SOP
Package Shape RECTANGULAR
Package Style SMALL OUTLINE
Parallel/Serial PARALLEL
Programming Voltage (V) 5
DLA Qualification Not Qualified
Seated Height-Max (mm) 2.6500
Supply Voltage-Max (V) 5.50000
Supply Voltage-Min (V) 4.50000
Supply Voltage-Nom (V) 5
Surface Mount YES
Technology CMOS
Temperature Grade INDUSTRIAL
Terminal Form GULL WING
Terminal Pitch (mm) 1.270
Terminal Position DUAL
Width (mm) 7.5000
Write Cycle Time-Max (tWC) (ms) 5.0000000000000000
