(25 PCS) S-1721A2818-I6T1G ABLIC LDO Regulator Pos 1.8V2.6V 0.15A 6-Pin SNT-6A

$23.95
Unit price per

Tax included.

THIS LISTING IS FOR (25 PCS) OF S-1721A2818-I6T1G BY ABLIC (Sii)

LDO Regulator Pos 1.8V2.6V 0.15A 6-Pin SNT-6A

Part #: S-1721A2818-I6T1G

Part Category: Regulators

Manufacturer: Seiko Instruments USA, Inc.

Description: Fixed Positive LDO Regulator, 2 Output, 2.8V1, 1.8V2, CMOS, PDSO6

Mfr Package Description LEAD FREE, SNT-6

REACH Compliant Yes

EU RoHS Compliant Yes

Status Transferred

Regulator Type FIXED POSITIVE MULTIPLE OUTPUT LDO REGULATOR

Dropout Voltage1-Max 0.23 V

Dropout Voltage2-Max 0.35 V

Input Voltage-Min 1.7 V

Input Voltage-Max 6.5 V

JESD-30 Code R-PDSO-F6

Number of Functions 1

Number of Outputs 2.0

Number of Terminals 6

Output Voltage1-Nom 2.8 V

Output Voltage1-Min 2.772 V

Output Voltage1-Max 2.828 V

Output Voltage2-Nom 1.8 V

Output Voltage2-Min 1.782 V

Output Voltage2-Max 1.818 V

Package Body Material PLASTIC/EPOXY

Package Code VSOF

Package Shape RECTANGULAR

Package Style SMALL OUTLINE, VERY THIN PROFILE

Peak Reflow Temperature (Cel) NOT SPECIFIED

Qualification Status Not Qualified

Seated Height-Max 0.5 mm

Surface Mount YES

Technology CMOS

Terminal Form FLAT

Terminal Pitch 0.5 mm

Terminal Position DUAL

Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED

Length 1.6 mm

Width 1.57 mm
