(25 PCS) MMBT2222ALT1G ONSEMI TRANS NPN 40V 0.6A SOT23-3 ROHS
Tax included.
THIS IS FOR (25 PCS) OF MMBT2222ALT1G BY ONSEMI
TRANS NPN 40V 0.6A SOT23-3 ROHS
Manufacturer: onsemi
Product Category: Bipolar Transistors - BJT
RoHS: YES
Mounting Style: SMD/SMT
Package / Case: SOT-23-3
Transistor Polarity: NPN
Configuration: Single
Collector- Emitter Voltage VCEO Max: 40 V
Collector- Base Voltage VCBO: 75 V
Emitter- Base Voltage VEBO: 6 V
Collector-Emitter Saturation Voltage: 1 V
Maximum DC Collector Current: 600 mA
Pd - Power Dissipation: 225 mW
Gain Bandwidth Product fT: 300 MHz
Minimum Operating Temperature: - 55 C
Maximum Operating Temperature: + 150 C
Series: MMBT2222AL
Packaging: Reel
Packaging: Cut Tape
Brand: onsemi
Continuous Collector Current: 600 mA
Height: 0.94 mm
Length: 2.9 mm
Product Type: BJTs - Bipolar Transistors
3000
Subcategory: Transistors
Technology: Si
Width: 1.3 mm
Unit Weight: 0.001058 oz
