(25 PCS) LQH4N271K04 1 ELEMENT 270uH FERRITE-CORE GENERAL PURPOSE INDUCTOR SMD

  • $4.95
    Unit price per
Tax included.

Only 160 left!

THIS LISTING IS FOR (25 PCS) OF LQH4N271K04 BY MURATA
1 ELEMENT 270uH FERRITE-CORE GENERAL PURPOSE INDUCTOR SMD

Part #: LQH4N271K04M00

Part Category: Inductors
Manufacturer: Murata Manufacturing Co., Ltd.
Description: 1 ELEMENT, 270uH, FERRITE-CORE, GENERAL PURPOSE INDUCTOR, SMD



Status Discontinued
Inductor Type GENERAL PURPOSE INDUCTOR
Core Material FERRITE
DC Resistance 6.8 ohm
Inductance-Nom (L) 270.0 µH
Inductor Application RF INDUCTOR
Manufacturer Series LQH4N
Number of Functions 1
Number of Terminals 2
Operating Temperature-Min -25.0 Cel
Operating Temperature-Max 85.0 Cel
Quality Factor-Min (at L-nom) 40.0
Rated Current-Max 0.1 A
Self Resonance Frequency 4.0 MHz
Shape/Size Description RECTANGULAR PACKAGE
Shielded NO
Special Feature Q MEASURED AT 0.796 MHZ
Surface Mount YES
Terminal Placement DUAL ENDED
Terminal Shape J BEND
Test Frequency 1.0 MHz
Tolerance 10.0 %
