(25 PCS) IR2113PBF IR Half-Bridge Gate Driver IC Non-Inverting 14-DIP ROHS
(25 PCS) IR2113PBF IR Half-Bridge Gate Driver IC Non-Inverting 14-DIP ROHS
(25 PCS) IR2113PBF IR Half-Bridge Gate Driver IC Non-Inverting 14-DIP ROHS
(25 PCS) IR2113PBF IR Half-Bridge Gate Driver IC Non-Inverting 14-DIP ROHS

(25 PCS) IR2113PBF IR Half-Bridge Gate Driver IC Non-Inverting 14-DIP ROHS

Tax included.
Only 107 left!
THIS IS FOR (25 PCS) OF IR2113PBF BY IR
Half-Bridge Gate Driver IC Non-Inverting 14-DIP ROHS

Manufacturer: Infineon
Product Category: Gate Drivers
RoHS: Y
Product: IGBT, MOSFET Gate Drivers
Type: High Side, Low Side
Mounting Style: Through Hole
Package / Case: PDIP-14
Number of Drivers: 2 Driver
Number of Outputs: 2 Output
Output Current: 2.5 A
Supply Voltage - Min: 10 V
Supply Voltage - Max: 20 V
Configuration: High Side, Low Side
Rise Time: 35 ns
Fall Time: 25 ns
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: + 125 C
Packaging: Tube
Features: Independent
Height: 5.33 mm
Length: 20.19 mm
Technology: Si
Width: 7.11 mm
Brand: Infineon / IR
Logic Type: CMOS, TTL
Propagation Delay - Max: 150 ns
Maximum Turn-Off Delay Time: 94 ns
Maximum Turn-On Delay Time: 120 ns
Operating Supply Current: 340 uA
Pd - Power Dissipation: 1.6 W
Product Type: Gate Drivers
Factory Pack Quantity: 25
Subcategory: PMIC - Power Management ICs
Part # Aliases: IR2113PBF SP001539158
Unit Weight: 0.056438 oz
