(25 PCS) HI1206N101R-10 Ferrite Beads 100ohms 100MHz 3A Monolithic 1206 SMD ROHS
Tax included.
THIS IS FOR (25 PCS) OD HI1206N101R-10 BY LAIRD
Ferrite Beads 100ohms 100MHz 3A Monolithic 1206 SMD ROHS
Manufacturer: Laird (Steward)
Product Category: Ferrite Beads
RoHS: Y
Series: HI
Product: Ferrite Chip Beads
Termination Style: SMD/SMT
Package / Case: 1206 (3216 metric)
Impedance: 100 Ohms
Maximum DC Current: 3 A
Maximum DC Resistance: 35 mOhms
Minimum Operating Temperature: - 55 C
Maximum Operating Temperature: + 125 C
Length: 3.2 mm
Width: 1.6 mm
Height: 1.1 mm
Diameter: -
Packaging: Reel
Packaging: Cut Tape
Brand: Laird Performance Materials
Capacitance: -
Product Type: Ferrite Beads
3000
Subcategory: Ferrites
Termination: -
Test Frequency: 100 MHz
Type: Differential Mode Ferrite Chip Bead Power
Unit Weight: 0.001623 oz
