(25 PCS) DO3316P-222 COILCRAFT Power Inductors SMD 2.2uH Unshld 20% 6.1A 12mOhms
(25 PCS) DO3316P-222 COILCRAFT Power Inductors SMD 2.2uH Unshld 20% 6.1A 12mOhms
(25 PCS) DO3316P-222 COILCRAFT Power Inductors SMD 2.2uH Unshld 20% 6.1A 12mOhms

(25 PCS) DO3316P-222 COILCRAFT Power Inductors SMD 2.2uH Unshld 20% 6.1A 12mOhms

Tax included.
Only 40 left!
THIS IS FOR (25 PCS) OF DO3316P-222 BY COILCRAFT
Power Inductors SMD 2.2uH Unshld 20% 6.1A 12mOhms

Status Discontinued
Inductor Type GENERAL PURPOSE INDUCTOR
Case/Size Code 5137
Construction Wirewound
Core Material FERRITE
DC Resistance 0.012  ohm
Inductance-Nom (L) 2.2  µH
Inductor Application DC-DC CONVERTER
JESD-609 Code e4
Number of Functions 1
Number of Terminals 2
Operating Temperature-Min -40.0  Cel
Operating Temperature-Max 85.0  Cel
Package Height 5.21  mm
Package Length 12.95  mm
Package Width 9.4  mm
Packing Method TR, 13 Inch
Rated Current-Max 6.1  A
Self Resonance Frequency 80.0  MHz
Shape/Size Description RECTANGULAR PACKAGE
Shielded NO
Special Feature NO
Surface Mount YES
Terminal Placement DUAL ENDED
Terminal Shape WRAPAROUND
Test Frequency 0.1  MHz
Tolerance 20.0  %
