(25 pcs) 598-8710-307F DIALIGHT LED RGB CLEAR 0606 SMD (1616 Metric) ROHS
(25 pcs) 598-8710-307F DIALIGHT LED RGB CLEAR 0606 SMD (1616 Metric) ROHS
(25 pcs) 598-8710-307F DIALIGHT LED RGB CLEAR 0606 SMD (1616 Metric) ROHS
(25 pcs) 598-8710-307F DIALIGHT LED RGB CLEAR 0606 SMD (1616 Metric) ROHS
(25 pcs) 598-8710-307F DIALIGHT LED RGB CLEAR 0606 SMD (1616 Metric) ROHS

(25 pcs) 598-8710-307F DIALIGHT LED RGB CLEAR 0606 SMD (1616 Metric) ROHS

Tax included.
Only 80 left!
THIS LISTING IS FOR (25 pcs) OF 598-8710-307F BY DIALIGHT
DIALIGHT LED RGB CLEAR 0606 SMD (1616 Metric) ROHS
Manufacturer Dialight
Series 598
Packaging Cut Tape (CT)
Part Status Active
Color Red, Green, Blue (RGB)
Configuration Common Anode
Lens Color Colorless
Lens Transparency Clear
Millicandela Rating 60mcd Red, 120mcd Green, 90mcd Blue
Lens Style Rectangle with Flat Top
Lens Size 1.10mm x 0.90mm
Voltage - Forward (Vf) (Typ) 2V Red, 3.2V Green, 3.2V Blue
Current - Test 20mA Red, 20mA Green, 20mA Blue
Viewing Angle 140°
Mounting Type Surface Mount
Wavelength - Dominant 635nm Red, 525nm Green, 470nm Blue
Wavelength - Peak -
Features -
Package / Case 0606 (1616 Metric)
Supplier Device Package 0606
Size / Dimension 1.60mm L x 1.60mm W
Height (Max) 0.70mm
