(20PCS) BYS21-45 1A, 45V, SILICON, SIGNAL DIODE
Tax included.
THIS LISTING IS FOR (20PCS) OF BYS21-45 BY SIEMENS
SPECIFICATIONS
| Mfr Package Description | SK1, 2 PIN |
| Status | Discontinued |
| Diode Type | RECTIFIER DIODE |
| Case Connection | ISOLATED |
| Configuration | SINGLE |
| Diode Element Material | SILICON |
| Forward Voltage-Max (VF) | 0.55 V |
| JESD-30 Code | O-PALF-W2 |
| JESD-609 Code | e0 |
| Moisture Sensitivity Level | NOT SPECIFIED |
| Non-rep Pk Forward Current-Max | 50.0 A |
| Number of Elements | 1.0 |
| Number of Terminals | 2 |
| Operating Temperature-Max | 125.0 Cel |
| Output Current-Max | 1.0 A |
| Package Body Material | PLASTIC/EPOXY |
| Package Shape | ROUND |
| Package Style | LONG FORM |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED |
| Qualification Status | Not Qualified |
| Rep Pk Reverse Voltage-Max | 45.0 V |
| Sub Category | Rectifier Diodes |
| Surface Mount | NO |
| Technology | SCHOTTKY |
| Terminal Finish | Tin/Lead (Sn/Pb) |
| Terminal Form | WIRE |
| Terminal Position | AXIAL |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
