(2000) LQN21A56NJ04M00 General Purpose Inductor .056uH 5% 1 Element Air-Core SMD
Tax included.
THIS LISTING IS FOR (2000 PCS) OF LQN21A56NJ04M00 BY MURATA
General Purpose Inductor 0.056uH 5% 1 Element Air-Core SMD
Part #: LQN21A56NJ04M00
Part Category: Inductors
Manufacturer: Murata Manufacturing Co., Ltd.
Description: General Purpose Inductor, 0.056uH, 5%, 1 Element, Air-Core, SMD
Status Discontinued
Inductor Type GENERAL PURPOSE INDUCTOR
Core Material AIR
DC Resistance 0.26 ohm
Inductance-Nom (L) 0.056 µH
Inductor Application RF INDUCTOR
Manufacturer Series LQN21A
Number of Functions 1
Number of Terminals 2
Operating Temperature-Min -25.0 Cel
Operating Temperature-Max 85.0 Cel
Quality Factor-Min (at L-nom) 40.0
Rated Current-Max 0.43 A
Self Resonance Frequency 1500.0 MHz
Shape/Size Description CYLINDRICAL PACKAGE
Shielded NO
Special Feature Q MEASURED AT 200 MHZ
Surface Mount YES
Terminal Placement DUAL ENDED
Terminal Shape J BEND
Test Frequency 100.0 MHz
Tolerance 5.0 %
