(20 PCS) B3F-4055 OMRON Tactile Switches 12x12mm Std Ht .3 High-force 260g ROHS
Tax included.
THIS LISTING IS FOR (20 PCS) OF B3F-4055 BY OMRON
Tactile Switches 12x12mm Std Ht .3 High-force 260g ROHS
| Manufacturer | Omron Electronics Inc-EMC Div | |
|---|---|---|
| Series | B3F | |
| Packaging | Bulk | |
| Part Status | Active | |
| Circuit | SPST-NO | |
| Switch Function | Off-Mom | |
| Contact Rating @ Voltage | 0.05A @ 24VDC | |
| Actuator Type | Plunger for Cap | |
| Mounting Type | Through Hole | |
| Actuator Height off PCB, Vertical | 7.30mm | |
| Actuator Length, Right Angle | - | |
| Actuator Orientation | Top Actuated | |
| Termination Style | PC Pin | |
| Outline | 12.00mm x 12.00mm | |
| Illumination | Non-Illuminated | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Operating Force | 260gf | |
| Ingress Protection | - | |
| Features | - | |
| Operating Temperature | -25°C ~ 70°C | |
| Actuator Material | - | |
| Switch Travel | 0.30mm | |
| Mechanical Life | 1,000,000 Cycles |
