(20 PCS) AT93C46-10PI-2.7 EEPROM 1K-Bit 128 x 8/64 x 16 3.3V/5V 8-Pin PDIP

AT93C46-10PI-2.7 Part Details & Parametric

Max. Operating Temperature (°C) 85

Screening Level Industrial

Density (bit) 1K

Interface Type Serial-3Wire

Organization 128x8|64x16

Min. Operating Temperature (°C) -40

Maximum Operating Frequency (MHz) 1

Max. Access Time (ns) 250

Typical Operating Supply Voltage (V) 3.3|5

Operating Current (mA) 2

Hardware Data Protection Yes

Data Retention (Year) 100

Minimum Operating Supply Voltage (V) 2.7

Maximum Operating Supply Voltage (V) 5.5

Programmability Yes

Mounting Through Hole

Package Height (mm) 3.3

Package Length (mm) 9.27

Package Width (mm) 6.35

PCB 8

Standard Package Name PDIP

Supplier Package PDIP

Pin Count 8

Lead Shape Through Hole
