(2 PCS) MT55L64L32F1T-12 MICRON 64KX32 ZBT SRAM, 9ns, PQFP100
Tax included.
THIS LISTING IS FOR (2 PCS) OF MT55L64L32F1T-12 BY MICRON
64KX32 ZBT SRAM, 9ns, PQFP100
64KX32 ZBT SRAM, 9ns, PQFP100
Part #: MT55L64L32F1T-12
SPECIFICATIONS
| Mfr Package Description | TQFP-100 |
| Status | Transferred |
| Sub Category | SRAMs |
| Access Time-Max | 9 ns |
| I/O Type | COMMON |
| JESD-30 Code | R-PQFP-G100 |
| JESD-609 Code | e0 |
| Memory Density | 2.10E6 bit |
| Memory IC Type | ZBT SRAM |
| Memory Width | 32 |
| Number of Functions | 1 |
| Number of Terminals | 100 |
| Number of Words | 65536 words |
| Number of Words Code | 64K |
| Operating Mode | SYNCHRONOUS |
| Operating Temperature-Min | 0.0 Cel |
| Operating Temperature-Max | 70 Cel |
| Organization | 64KX32 |
| Output Characteristics | 3-STATE |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | LQFP |
| Package Equivalence Code | QFP100,.63X.87 |
| Package Shape | RECTANGULAR |
| Package Style | FLATPACK, LOW PROFILE |
| Parallel/Serial | PARALLEL |
| Power Supplies (V) | 3.3 |
| Qualification Status | Not Qualified |
| Seated Height-Max | 1.6 mm |
| Standby Current-Max | 0.0100 Amp |
| Standby Voltage-Min | 3.14 V |
| Supply Current-Max | 0.1850 Amp |
| Supply Voltage-Nom (Vsup) | 3.3 V |
| Supply Voltage-Min (Vsup) | 3.13 V |
| Supply Voltage-Max (Vsup) | 3.46 V |
| Surface Mount | YES |
| Technology | CMOS |
| Temperature Grade | COMMERCIAL |
| Terminal Finish | Tin/Lead (Sn/Pb) |
| Terminal Form | GULL WING |
| Terminal Pitch | 0.6500 mm |
| Terminal Position | QUAD |
| Length | 20 mm |
| Width | 14 mm |
