(2 PCS) MT55L256V36PB-7.5A MICRON ZBT SRAM, 256KX36, 4.2ns, CMOS, BGA-119
Tax included.
THIS IS FOR (2 PCS) OF MT55L256V36PB-7.5A
BY MICRON
ZBT SRAM, 256KX36, 4.2ns, CMOS, BGA-119
Mfr Package Description 14 X 22 MM, PLASTIC, MS-028BHA, BGA-119
Status Transferred
Sub Category SRAMs
Access Time-Max 4.2 ns
I/O Type COMMON
JESD-30 Code R-PBGA-B119
JESD-609 Code e0
Memory Density 9437184.0 bit
Memory IC Type ZBT SRAM
Memory Width 36
Number of Functions 1
Number of Terminals 119
Number of Words 262144.0 words
Number of Words Code 256K
Operating Mode SYNCHRONOUS
Operating Temperature-Min 0.0 Cel
Operating Temperature-Max 70.0 Cel
Organization 256KX36
Output Characteristics 3-STATE
Package Body Material PLASTIC/EPOXY
Package Code BGA
Package Equivalence Code BGA119,7X17,50
Package Shape RECTANGULAR
Package Style GRID ARRAY
Parallel/Serial PARALLEL
Qualification Status Not Qualified
Seated Height-Max 2.4 mm
Standby Current-Max 0.01 Amp
Standby Voltage-Min 3.14 V
Supply Current-Max 0.4 Amp
Supply Voltage-Nom (Vsup) 3.3 V
Supply Voltage-Min (Vsup) 3.135 V
Supply Voltage-Max (Vsup) 3.465 V
Surface Mount YES
Technology CMOS
Temperature Grade COMMERCIAL
Terminal Finish Tin/Lead (Sn/Pb)
Terminal Form BALL
Terminal Pitch 1.27 mm
Terminal Position BOTTOM
Length 22.0 mm
Width 14.0 mm
