(2 PCS) GAL20V8A-25LJ LATTICE SEMI. EE PLD, 25ns, CMOS, PLCC28
Tax included.
THIS IS FOR (2 PCS) OF GAL20V8A-25LJ BY LATTICE SEMI.
EE PLD, 25ns, CMOS, PLCC28
Part #: GAL20V8A-25LJ
Obsolete
Part Category: Programmable Logic Devices
Manufacturer: LATTICE SEMICONDUCTOR CORP
Description: EE PLD, 25ns, PAL-Type, CMOS, PQCC28
Status Discontinued
Additional Feature 8 MACROCELLS; 1 EXTERNAL CLOCK; REGISTER PRELOAD; SHARED INPUT/CLOCK
Architecture PAL-TYPE
Clock Frequency-Max (MHz) 37.00000
JESD-30 Code S-PQCC-J28
J-STD-609 Code e0
Length (mm) 11.5062
Moisture Sensitivity Level 1
Number of Dedicated Inputs 12
Number of I/O Lines 8
Number of Inputs 20
Number of Outputs 8
Number of Product Terms 64
Number of Terminals 28
Operating Temperature-Max (Cel) 75.0
Operating Temperature-Min (Cel) 0.0
Organization 12 DEDICATED INPUTS, 8 I/O
Output Function MACROCELL
Package Body Material PLASTIC/EPOXY
Package Code QCCJ
Package Equivalence Code LDCC28,.5SQ
Package Shape SQUARE
Package Style CHIP CARRIER
Peak Reflow Temperature (Cel) 225
Programmable Logic Type EE PLD
Propagation Delay (ns) 25.000
DLA Qualification Not Qualified
Seated Height-Max (mm) 4.5700
Supply Voltage-Max (V) 5.25000
Supply Voltage-Min (V) 4.75000
Supply Voltage-Nom (V) 5
Surface Mount YES
Technology CMOS
Temperature Grade COMMERCIAL EXTENDED
Terminal Finish Tin/Lead (Sn85Pb15)
Terminal Form J BEND
Terminal Pitch (mm) 1.270
Terminal Position QUAD
Time@Peak Reflow Temperature-Max (s) 30
Width (mm) 11.5062
