(2 PCS) AM29C843AJC AMD CMOS SERIES 9-BIT DRIVER TRUE OUTPUT PLCC28
Tax included.
THIS LISTING IS FOR (2 PCS) OF AM29C843AJC BY AMD
CMOS SERIES 9-BIT DRIVER TRUE OUTPUT PLCC28
Manufacturer: Advanced Micro Devices, Inc.
Description: CMOS SERIES, 9-BIT DRIVER, TRUE OUTPUT, PLCC28
Mfr Package Description
CMOS SERIES 9-BIT DRIVER TRUE OUTPUT PLCC28
Part #: AM29C843AJC
Part Category: Logic ICsManufacturer: Advanced Micro Devices, Inc.
Description: CMOS SERIES, 9-BIT DRIVER, TRUE OUTPUT, PLCC28
Mfr Package Description
| PLASTIC, LCC-28 | |
| Status | Discontinued |
| Logic IC Type | BUS DRIVER |
| Sub Category | FF/Latches |
| Family | CMOS |
| JESD-30 Code | S-PQCC-J28 |
| JESD-609 Code | e0 |
| Load Capacitance (CL) | 300.0 pF |
| Max I(ol) | 0.048 Amp |
| Number of Bits | 9 |
| Number of Functions | 1 |
| Number of Ports | 2 |
| Number of Terminals | 28 |
| Operating Temperature-Min | 0.0 Cel |
| Operating Temperature-Max | 70.0 Cel |
| Output Characteristics | 3-STATE |
| Output Polarity | TRUE |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | QCCJ |
| Package Equivalence Code | LDCC28,.5SQ |
| Package Shape | SQUARE |
| Package Style | CHIP CARRIER |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED |
| Power Supplies (V) | 5 |
| Prop. Delay@Nom-Sup | 11.0 ns |
| Propagation Delay (tpd) | 16.5 ns |
| Qualification Status | Not Qualified |
| Seated Height-Max | 4.57 mm |
| Supply Voltage-Nom (Vsup) | 5 |
| Supply Voltage-Min (Vsup) | 4.5 V |
| Supply Voltage-Max (Vsup) | 5.5 V |
| Surface Mount | YES |
| Technology | CMOS |
| Temperature Grade | COMMERCIAL |
| Terminal Finish | Tin/Lead (Sn/Pb) |
| Terminal Form | J BEND |
| Terminal Pitch | 1.27 mm |
| Terminal Position | QUAD |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
| Length | 11.5062 mm |
| Width | 11.5062 mm |
| Additional Feature | WITH CLEAR AND PRESET |
