(2 PCS) AM26LS30JC AMD QUAD LINE DRIVER, PLCC20
Tax included.
THIS IS FOR (2 PCS) OF AM26LS30JC BY AMD
QUAD LINE DRIVER, PLCC20
Part #: AM26LS30JC
Part Category: Interface ICs
Manufacturer: Advanced Micro Devices, Inc.
Description: Line Driver, 4 Func, 4 Driver, BIPolar, PQCC20
Mfr Package Description PLASTIC, LCC-20
Status Discontinued
Interface IC Type LINE DRIVER
Differential Output YES
Driver Number of Bits 4.0
High Level Input Current-Max 4.0E-5 Amp
Input Characteristics STANDARD
Interface Standard EIA-422; EIA-423
JESD-30 Code S-PQCC-J20
JESD-609 Code e0
Negative Supply Voltage-Nom -5.0 V
Number of Functions 4
Number of Terminals 20
Operating Temperature-Min 0.0 Cel
Operating Temperature-Max 70.0 Cel
Out Swing-Min 2.0 V
Output Characteristics 3-STATE
Output Polarity COMPLEMENTARY
Package Body Material PLASTIC/EPOXY
Package Code QCCJ
Package Equivalence Code LDCC20,.4SQ
Package Shape SQUARE
Package Style CHIP CARRIER
Peak Reflow Temperature (Cel) NOT SPECIFIED
Qualification Status Not Qualified
Receive Delay-Max 0.0 ns
Seated Height-Max 4.572 mm
Sub Category Line Driver or Receivers
Supply Current-Max 30.0 mA
Supply Voltage-Nom 5.0 V
Supply Voltage-Min 4.75 V
Supply Voltage-Max 5.25 V
Surface Mount YES
Technology BIPOLAR
Temperature Grade COMMERCIAL
Terminal Finish Tin/Lead (Sn/Pb)
Terminal Form J BEND
Terminal Pitch 1.27 mm
Terminal Position QUAD
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Transmit Delay-Max 200.0 ns
Length 8.9662 mm
Width 8.9662 mm
Additional Feature PROGRAMMABLE SLEW RATE
