THIS LISTING IS FOR (2 PCS) OF 5760-392J 1812R-392J BY API DELEVAN
Fixed Inductors 3.9uH 5%SMD ROHS

Part #: 1812-392J
Part Category: Inductors
Manufacturer: API Delevan, Inc.
Description: General Purpose Inductor, 3.9uH, 5%, 1 Element, Ferrite-Core, SMD, 1812

Mfr Package Description CHIP, 1812
REACH Compliant Yes
EU RoHS Compliant Yes
Status Active
Inductor Type GENERAL PURPOSE INDUCTOR
Case/Size Code 1812
Construction Unshielded
Core Material FERRITE
DC Resistance 0.9  ohm
Inductance-Nom (L) 3.9  µH
Inductor Application RF INDUCTOR
JESD-609 Code e1
Number of Functions 1
Number of Terminals 2
Operating Temperature-Min -55.0  Cel
Operating Temperature-Max 125.0  Cel
Package Height 3.2  mm
Package Length 4.525  mm
Package Width 3.2  mm
Packing Method TR, 7/13 Inch
Quality Factor-Min (at L-nom) 50.0
Rated Current-Max 0.472  A
Self Resonance Frequency 40.0  MHz
Shape/Size Description RECTANGULAR PACKAGE
Shielded NO
Surface Mount YES
Terminal Finish Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5)
Terminal Placement DUAL ENDED
Terminal Shape WRAPAROUND
Test Frequency 7.9  MHz
Tolerance 5.0  %
