(2 PCS) 2N3440_PBFREE CENTRAL Trans GP BJT NPN 250V 1A 1000mW 3-Pin TO-39 ROHS
(2 PCS) 2N3440_PBFREE CENTRAL Trans GP BJT NPN 250V 1A 1000mW 3-Pin TO-39 ROHS
(2 PCS) 2N3440_PBFREE CENTRAL Trans GP BJT NPN 250V 1A 1000mW 3-Pin TO-39 ROHS
(2 PCS) 2N3440_PBFREE CENTRAL Trans GP BJT NPN 250V 1A 1000mW 3-Pin TO-39 ROHS
(2 PCS) 2N3440_PBFREE CENTRAL Trans GP BJT NPN 250V 1A 1000mW 3-Pin TO-39 ROHS

(2 PCS) 2N3440_PBFREE CENTRAL Trans GP BJT NPN 250V 1A 1000mW 3-Pin TO-39 ROHS

Tax included.
Only 134 left!
THIS IS FOR (2 PCS) 2N3440_PBFREE CENTRAL
Trans GP BJT NPN 250V 1A 1000mW 3-Pin TO-39 ROHS

Manufacturer: Central Semiconductor
Product Category: Bipolar Transistors - BJT
RoHS:  YES
Mounting Style: Through Hole
Package / Case: TO-39
Transistor Polarity: NPN
Configuration: Single
Collector- Emitter Voltage VCEO Max: 250 V
Collector- Base Voltage VCBO: 350 V
Emitter- Base Voltage VEBO: 7 V
Collector-Emitter Saturation Voltage: 500 mV
Maximum DC Collector Current: 1 A
Pd - Power Dissipation: 1 W
Gain Bandwidth Product fT: 15 MHz
Minimum Operating Temperature: - 65 C
Maximum Operating Temperature: + 200 C
Packaging: Bulk
Brand: Central Semiconductor
Continuous Collector Current: 1 A
DC Collector/Base Gain hfe Min: 40
DC Current Gain hFE Max: 160
Product Type: BJTs - Bipolar Transistors
500
Subcategory: Transistors
Unit Weight: 0.089217 oz
