(1PC)SN75ALS170DW TI Line Transceiver, 3 Func, 3 Driver, 3 Rec, BIPolar, SOIC20
Tax included.
This listing is for (1PC) of SN75ALS170DW by Texas Instruments.
Mfr Package Description SOIC-20
REACH Compliant Yes
EU RoHS Compliant Yes
China RoHS Compliant Yes
Status Active
Interface IC Type LINE TRANSCEIVER
Differential Output YES
Driver Number of Bits 3.0
High Level Input Current-Max 2.0E-5 Amp
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Interface Standard EIA-422-B; TIA-422-B; EIA-485; V.11
JESD-30 Code R-PDSO-G20
JESD-609 Code e4
Moisture Sensitivity Level 1
Number of Functions 3
Number of Terminals 20
Operating Temperature-Min 0.0 Cel
Operating Temperature-Max 70.0 Cel
Out Swing-Min 1.5 V
Output Characteristics 3-STATE
Output Low Current-Max 0.008 Amp
Output Polarity TRUE
Package Body Material PLASTIC/EPOXY
Package Code SOP
Package Equivalence Code SOP20,.4
Package Shape RECTANGULAR
Package Style SMALL OUTLINE
Peak Reflow Temperature (Cel) 260
Qualification Status Not Qualified
Receive Delay-Max 19.0 ns
Receiver Number of Bits 3.0
Seated Height-Max 2.65 mm
Sub Category Line Driver or Receivers
Supply Current-Max 90.0 mA
Supply Voltage-Nom 5.0 V
Supply Voltage-Min 4.75 V
Supply Voltage-Max 5.25 V
Supply Voltage1-Nom 5.0 V
Supply Voltage1-Min 4.75 V
Supply Voltage1-Max 5.25 V
Surface Mount YES
Technology BIPOLAR
Temperature Grade COMMERCIAL
Terminal Finish NICKEL PALLADIUM GOLD
Terminal Form GULL WING
Terminal Pitch 1.27 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 30
Transmit Delay-Max 13.0 ns
Length 12.8 mm
Width 7.5 mm
Additional Feature COMMON I/O
