(1PC) W5I-BO-07 2.4GHz 2.5dBi U.FL (UMCC) Bluetooth, WLAN, Zigbee™ PCB Trace RF
Tax included.
THIS LISTING IS FOR (1PC) OF W5I-BO-07 BY WIZnet
2.4GHz 2.5dBi U.FL (UMCC) Bluetooth, WLAN, Zigbee™ PCB Trace RF Antenna
Manufacturer: WIZnet
Product Category: Antennas
RoHS: Details
Product Type: 2.4GHz Antenna - 2.4GHz, 5GHz, Bluetooth, WiFi, WLAN, Zigbee
Product: PCB Antennas
Type: Passive Antenna
Minimum Frequency: 2.4 GHz
Maximum Frequency: 2.484 GHz
Protocol - WiFi - 802.11: 802.11, WLAN, WiFi, WiMAX
Protocol - Sub GHz: IoT, ISM
Mechanical Style: PCB Trace
Style: I-Bar
Gain: 2.5 dBi
Bandwidth: 83.5 MHz
Impedance: 50 Ohms
VSWR: 1.9
Minimum Operating Temperature: - 30 C
Maximum Operating Temperature: + 70 C
Electrical Type: Embedded
Number of Bands: 1 Band
Mounting Style: Adhesive Mount
Termination Style: Connector
Antenna Connector Type: IPEX MHF1
Center Frequency: 2450 MHz
Application: Wireless Application
Length: 48 mm
Width: 8 mm
Height: 1 mm
Cable Type: 130 mm RF1.13
Brand: WIZnet
