(1PC) TLN50 TLN050 Electric Fuse, Fast Blow, 50A, 170VDC
Tax included.
This listing is for (1 Fuse) TLN050 by Littelfuse
Status Active
Additional Feature RATED BREAKING CAPACITY AT 170 VDC: 100000A
Blow Characteristic FAST
Body Height (mm) 76.2000
Body Length or Diameter (mm) 20.6000
Circuit Protection Type ELECTRIC FUSE
Mounting Feature INLINE/HOLDER
Rated Current (A) 50.00000000
Rated Voltage (DC) (V) 170.00000000
Screening Level / Reference Standard UL
Terminal Shape END CAP
