(1PC) PLDC20RA10-30PC OT PLD, 30ns, PAL-Type, CMOS, PDIP24
Tax included.
THIS LISTING IS FOR (1PC) OF PLDC20RA10-30PC BY CYPRESS SEMICONDUCTOR
Mfr Package Description 0.300 INCH, PLASTIC, DIP-24
Status Discontinued
Programmable Logic Type OT PLD
Architecture PAL-TYPE
Clock Frequency-Max 22.2 MHz
JESD-30 Code R-PDIP-T24
JESD-609 Code e0
Number of Dedicated Inputs 10.0
Number of I/O Lines 10.0
Number of Inputs 20.0
Number of Outputs 10.0
Number of Product Terms 80.0
Number of Terminals 24
Operating Temperature-Min 0.0 Cel
Operating Temperature-Max 75.0 Cel
Organization 10 DEDICATED INPUTS, 10 I/O
Output Function MACROCELL
Package Body Material PLASTIC/EPOXY
Package Code DIP
Package Equivalence Code DIP24,.3
Package Shape RECTANGULAR
Package Style IN-LINE
Power Supplies 5
Propagation Delay 30.0 ns
Qualification Status Not Qualified
Seated Height-Max 4.826 mm
Sub Category Programmable Logic Devices
Supply Voltage-Nom 5.0 V
Supply Voltage-Min 4.5 V
Supply Voltage-Max 5.5 V
Surface Mount NO
Technology CMOS
Temperature Grade COMMERCIAL EXTENDED
Terminal Finish TIN LEAD
Terminal Form THROUGH-HOLE
Terminal Pitch 2.54 mm
Terminal Position DUAL
Length 30.099 mm
Width 7.62 mm
