(1pc) NMXS0505SO NEWPORT DC-DC Regulated Power Supply Module 1 Output 5W Hybrid
Tax included.
THIS IS FOR (1pc) OF NMXS0505SO BY NEWPORT COMPONENTS LTD
DC-DC Regulated Power Supply Module, 1 Output, 5W, Hybrid
Part #: NMXS0505SO
Other
Part Category: Power Supply Modules
Manufacturer: NEWPORT COMPONENTS LTD
Description: DC-DC Regulated Power Supply Module, 1 Output, 5W, Hybrid
Status Transferred
Analog IC - Other Type DC-DC REGULATED POWER SUPPLY MODULE
Efficiency (Main Output) (%) 65.000000
Input Voltage-Max (V) 5.5000000000000000
Input Voltage-Min (V) 4.5000000000000000
Input Voltage-Nom (V) 5
JESD-30 Code R-PDIP-P4
Line Regulation-Max (%) 0.500000
Load Regulation-Max (%) 0.500000
Number of Functions 1
Number of Outputs 1
Number of Terminals 4
Operating Temperature-Max (Cel) 70
Operating Temperature-Min (Cel) 0
Output Voltage-Max (V) 5.1500000000000000
Output Voltage-Min (V) 4.8500000000000000
Output Voltage-Nom (V) 5.0000000000000000
Package Body Material PLASTIC/EPOXY
Package Shape RECTANGULAR
Package Style IN-LINE
Protections CURRENT
DLA Qualification Not Qualified
Surface Mount NO
Technology HYBRID
Temperature Grade COMMERCIAL
Terminal Form PIN/PEG
Terminal Position DUAL
Total Power Output-Max (W) 5.0000000000000000
Trim/Adjustable Output NO
