(1PC) MT58L256L18F1T-7.5 Micron Cache SRAM, 256KX18, 7.5ns, CMOS, PQFP100
(1PC) MT58L256L18F1T-7.5 Micron Cache SRAM, 256KX18, 7.5ns, CMOS, PQFP100
(1PC) MT58L256L18F1T-7.5 Micron Cache SRAM, 256KX18, 7.5ns, CMOS, PQFP100

(1PC) MT58L256L18F1T-7.5 Micron Cache SRAM, 256KX18, 7.5ns, CMOS, PQFP100

Tax included.
Only 108 left!
This listing is for (1PC) of MT58L256L18F1T-7.5 by Micron

Status Transferred
Access Time-Max (ns) 7.5000000000000000
Additional Feature FLOW-THROUGH ARCHITECTURE
Clock Frequency-Max (MHz) 113.00000
I/O Type COMMON
JESD-30 Code R-PQFP-G100
J-STD-609 Code e0
Length (mm) 20.0000
Memory Density (bits) 4718592.0000000000000000
Memory IC Type CACHE SRAM
Memory Width 18
Number of Functions 1
Number of Terminals 100
Number of Words (words) 262144.0000000000000000
Number of Words Code 256K
Operating Mode SYNCHRONOUS
Operating Temperature-Max (Cel) 70.0
Operating Temperature-Min (Cel) 0.0
Memory Organization 256KX18
Output Characteristics 3-STATE
Package Body Material PLASTIC/EPOXY
Package Code LQFP
Package Equivalence Code QFP100,.63X.87
Package Shape RECTANGULAR
Package Style FLATPACK, LOW PROFILE
Parallel/Serial PARALLEL
DLA Qualification Not Qualified
Seated Height-Max (mm) 1.6000
Standby Current-Max (A) 0.010000000000000
Standby Voltage-Min (V) 3.140000
Supply Current-Max (mA) 375.000000000000000
Supply Voltage-Max (V) 3.60000
Supply Voltage-Min (V) 3.13500
Supply Voltage-Nom (V) 3.3
Surface Mount YES
Technology CMOS
Temperature Grade COMMERCIAL
Terminal Finish Tin/Lead (Sn/Pb)
Terminal Form GULL WING
Terminal Pitch (mm) 0.650
Terminal Position QUAD
Width (mm) 14.0000
