(1pc) MR4A16BCYS35 EVERSPIN 16 Mb 3.6 V 35 ns Asynchronous MRAM Memory TSOP2-54
Tax included.
THIS LISTING IS FOR (1PC) OF MR4A16BCY35 BY EVERSPIN TECHNOLOGIES
Mfr Package Description TSOP2-54
REACH Compliant Yes
EU RoHS Compliant Yes
Status Active
Sub Category SRAMs
Access Time-Max 35.0 ns
JESD-30 Code R-PDSO-G54
Memory Density 1.6777216E7 bit
Memory IC Type MEMORY CIRCUIT
Memory Width 16
Number of Functions 1
Number of Terminals 54
Number of Words 1048576.0 words
Number of Words Code 1M
Operating Mode ASYNCHRONOUS
Operating Temperature-Min 0.0 Cel
Operating Temperature-Max 70.0 Cel
Organization 1MX16
Package Body Material PLASTIC/EPOXY
Package Code TSOP2
Package Equivalence Code TSOP54,.46,32
Package Shape RECTANGULAR
Package Style SMALL OUTLINE, THIN PROFILE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Qualification Status Not Qualified
Seated Height-Max 1.2 mm
Standby Current-Max 0.014 Amp
Supply Voltage-Nom (Vsup) 3.3 V
Supply Voltage-Min (Vsup) 3.0 V
Supply Voltage-Max (Vsup) 3.6 V
Surface Mount YES
Technology CMOS
Temperature Grade COMMERCIAL
Terminal Form GULL WING
Terminal Pitch 0.8 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Length 22.22 mm
Width 10.16 mm
