(1PC) MPC930FA Processor Specific Clock Generator, 140MHz, CMOS, PQFP32
Tax included.
THIS LISTING IS FOR (1PC) OF MPC930FA BY MOTOROLA
Mfr Package Description PLASTIC, TQFP-32
Status Transferred
JESD-30 Code S-PQFP-G32
JESD-609 Code e0
Number of Terminals 32
Operating Temperature-Min 0.0 Cel
Operating Temperature-Max 70.0 Cel
Output Clock Frequency-Max 140.0 MHz
Package Body Material PLASTIC/EPOXY
Package Code LQFP
Package Equivalence Code QFP32,.35SQ,32
Package Shape SQUARE
Package Style FLATPACK, LOW PROFILE
Power Supplies 3.3
Primary Clock/Crystal Frequency-Nom 20.0 MHz
Qualification Status Not Qualified
Seated Height-Max 1.6 mm
Sub Category Clock Generators
Supply Current-Max 105.0 mA
Supply Voltage-Nom 3.3 V
Supply Voltage-Min 3.135 V
Supply Voltage-Max 3.465 V
Surface Mount YES
Technology CMOS
Temperature Grade COMMERCIAL
Terminal Finish Tin/Lead (Sn/Pb)
Terminal Form GULL WING
Terminal Pitch 0.8 mm
Terminal Position QUAD
Length 7.0 mm
Width 7.0 mm
