(1PC) MC10E104FN AND/NAND Gate 5-Element 2-IN ECL 28-Pin PLCC
Tax included.
This listing is for (1PC) of MC10E104FN by Motorola
Mfr Package Description PLASTIC, LCC-28
Status Transferred
Logic IC Type AND/NAND GATE
Sub Category Gates
Family 10E
JESD-30 Code S-PQCC-J28
JESD-609 Code e0
Number of Functions 5
Number of Inputs 2.0
Number of Terminals 28
Operating Temperature-Min 0.0 Cel
Operating Temperature-Max 85.0 Cel
Output Characteristics OPEN-EMITTER
Package Body Material PLASTIC/EPOXY
Package Code QCCJ
Package Equivalence Code LDCC28,.5SQ
Package Shape SQUARE
Package Style CHIP CARRIER
Power Supply Current-Max (ICC) 46.0 mA
Prop. Delay@Nom-Sup 1.0 ns
Propagation Delay (tpd) 0.6 ns
Qualification Status Not Qualified
Schmitt Trigger NO
Seated Height-Max 4.57 mm
Surface Mount YES
Technology ECL
Temperature Grade OTHER
Terminal Finish Tin/Lead (Sn/Pb)
Terminal Form J BEND
Terminal Pitch 1.27 mm
Terminal Position QUAD
Length 11.505 mm
Width 11.505 mm
Additional Feature O/P'S CASCADED OR/NOR
