(1PC) M55302/58-A70Y Airborn Board Connector, 70 Contacts, 2 Row, Female
Tax included.
This listing is for (1PC) of M55302/58-A70Y by Airborn
Status Active
Additional Feature STANDARD: MIL-DTL-55302, PANEL MOUNTABLE
Body/Shell Style RECEPTACLE
Connector Type BOARD CONNECTOR
Contact Finish - Mating GOLD OVER NICKEL (150)
Contact Finish - Termination GOLD OVER NICKEL (150)
Contact Gender FEMALE
DIN Conformance NO
Filter Feature NO
IEC Conformance NO
J-STD-609 Code e4
MIL Conformance YES
Mating Information MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts NO
Number of Connectors ONE
Number of Rows Loaded 2
Option GENERAL PURPOSE
Rated Current (Signal) (A) 3.0000000000000000
Termination Type SOLDER
Number of Contacts 70
