(1PC) JM38510/00905BEB Parallel In/Out, TTL/H/L Series, 4-Bit, Bi, CDIP16
Tax included.
THIS LISTING IS FOR (1PC) OF JM38510/00905BEB BY MOTOROLA
Status Discontinued
Logic IC Type PARALLEL IN PARALLEL OUT
Count Direction BIDIRECTIONAL
Family TTL/H/L
fmax-Min 36.0 MHz
JESD-30 Code R-GDIP-T16
Load Capacitance (CL) 15.0 pF
Number of Bits 4
Number of Functions 1
Number of Terminals 16
Operating Temperature-Min -55.0 Cel
Operating Temperature-Max 125.0 Cel
Output Polarity TRUE
Package Body Material CERAMIC, GLASS-SEALED
Package Code DIP
Package Shape RECTANGULAR
Package Style IN-LINE
Power Supply Current-Max (ICC) 63.0 mA
Propagation Delay (tpd) 26.0 ns
Qualification Status Not Qualified
Seated Height-Max 5.08 mm
Supply Voltage-Nom (Vsup) 5
Supply Voltage-Min (Vsup) 4.5 V
Supply Voltage-Max (Vsup) 5.5 V
Surface Mount NO
Technology TTL
Terminal Form THROUGH-HOLE
Terminal Pitch 2.54 mm
Terminal Position DUAL
Trigger Type POSITIVE EDGE
Length 19.56 mm
Width 7.62 mm
Additional Feature HOLD MODE
