(1PC) ADG452BR ANALOG DEVICES Analog Switch Quad SPST 16-Pin SOIC
Tax included.
THIS LISTING IS FOR (1PC) OF ADG452BR BY ANALOG DEVICES
SPECIFICATIONS
| Mfr Package Description | MS-012AC, SOIC-16 |
| REACH Compliant | Yes |
| Status | Active |
| Analog IC - Other Type | SPST |
| JESD-30 Code | R-PDSO-G16 |
| JESD-609 Code | e0 |
| Moisture Sensitivity Level | 1 |
| Neg Supply Voltage-Nom (Vsup) | -5.0 V |
| Neg Supply Voltage-Min (Vsup) | -4.5 V |
| Neg Supply Voltage-Max (Vsup) | -20.0 V |
| Normal Position (V) | NO |
| Number of Channels | 1 |
| Number of Functions | 4 |
| Number of Terminals | 16 |
| Off-state Isolation-Nom | 65.0 dB |
| On-state Resistance Match-Nom | 0.3 ohm |
| On-state Resistance-Max (Ron) | 12.0 ohm |
| Operating Temperature-Min | -40.0 Cel |
| Operating Temperature-Max | 85.0 Cel |
| Output (V) | SEPARATE OUTPUT |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | SOP |
| Package Equivalence Code | SOP16,.25 |
| Package Shape | RECTANGULAR |
| Package Style | SMALL OUTLINE |
| Peak Reflow Temperature (Cel) | 240 |
| Power Supplies (V) | 5,12/+-15 |
| Qualification Status | Not Qualified |
| Seated Height-Max | 1.75 mm |
| Sub Category | Multiplexer or Switches |
| Supply Voltage-Nom (Vsup) | 5.0 V |
| Supply Voltage-Min (Vsup) | 4.5 V |
| Supply Voltage-Max (Vsup) | 20.0 V |
| Surface Mount | YES |
| Switch-off Time-Max | 140.0 ns |
| Switch-on Time-Max | 220.0 ns |
| Switching (V) | BREAK-BEFORE-MAKE |
| Technology | CMOS |
| Temperature Grade | INDUSTRIAL |
| Terminal Finish | Tin/Lead (Sn85Pb15) |
| Terminal Form | GULL WING |
| Terminal Pitch | 1.27 mm |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | 30 |
| Length | 9.9 mm |
| Width | 3.9 mm |
| Additional Feature | ALSO OPERATE WITH 12V SINGLE SUPPLY |
