(1PC) AD7376ARU10 Digital Potentiometer 128POS 10KOhm Single 14-Pin TSSOP
Tax included.
THIS LISTING IS FOR (1PC) OF AD7376ARU10 BY ANALOG DEVICES.
Digital Potentiometer 128POS 10KOhm Single 14-Pin TSSOP
AD7376ARU10 Part Details & Parametric
| EU RoHS | Not Compliant |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 85 |
| Resistance Value (kOhm) | 10 |
| Memory Type | Volatile |
| Number of Positions | 128 |
| Number of Pot per Package | 1 |
| Power Supply Type | Single|Dual |
| Maximum Dual Supply Voltage (V) | ±16.5 |
| Maximum Single Supply Voltage (V) | 33 |
| Screening Level | Extended Industrial |
| Minimum Dual Supply Voltage (V) | ±4.5 |
| Minimum Single Supply Voltage (V) | 4.5 |
| Typical Dual Supply Voltage (V) | ±15 |
| Typical Single Supply Voltage (V) | 30 |
| Control Interface | Serial (3-Wire, SPI) |
| Mounting | Surface Mount |
| Package Height (mm) | 1 |
| Package Length (mm) | 5 |
| Package Width (mm) | 4.4 |
| PCB | 14 |
| Standard Package Name | TSSOP |
| Supplier Package | TSSOP |
| Pin Count | 14 |
| Lead Shape | Gull-wing |
