(1PC) AD570JD 8-Bit, 1 Func, 1 Channel, Parallel, 8 Bits Access, Bipolar, CDIP18
Tax included.
THIS LISTING IS FOR (1PC) OF AD570JD BY ANALOG DEVICES
Mfr Package Description SIDE BRAZED, CERAMIC, DIP-18
Status NRFND
Converter Type ADC, SUCCESSIVE APPROXIMATION
Analog Input Voltage-Min -5.0 V
Analog Input Voltage-Max 5.0 V
Conversion Time-Max 40.0 µs
JESD-30 Code R-CDIP-T18
JESD-609 Code e0
Linearity Error-Max (EL) 0.2 %
Negative Supply Voltage-Nom -15.0 V
Number of Analog In Channels 1.0
Number of Bits 8
Number of Functions 1
Number of Terminals 18
Operating Temperature-Min 0.0 Cel
Operating Temperature-Max 70.0 Cel
Output Bit Code BINARY, OFFSET BINARY
Output Format PARALLEL, 8 BITS
Package Body Material CERAMIC, METAL-SEALED COFIRED
Package Code DIP
Package Equivalence Code DIP18,.3
Package Shape RECTANGULAR
Package Style IN-LINE
Qualification Status Not Qualified
Sample Rate 0.04 MHz
Seated Height-Max 5.08 mm
Sub Category Analog to Digital Converters
Supply Current-Max 15.0 mA
Supply Voltage-Nom 5.0 V
Surface Mount NO
Technology BIPOLAR
Temperature Grade COMMERCIAL
Terminal Finish TIN LEAD
Terminal Form THROUGH-HOLE
Terminal Pitch 2.54 mm
Terminal Position DUAL
Width 7.62 mm
