(1PC) 2N4963 RF Small Signal Bipolar Transistor 1A 1-Element NPN TO-18 (NTE128)
Tax included.
THIS IS FOR (1PC) OF 2N4963 BY FSC
RF Small Signal Bipolar Transistor 1A 1-Element NPN TO-18 CROSS TO (NTE128)
Part #: 2N4963
Obsolete
Part Category: Small Signal Bipolar Transistors
Manufacturer: FAIRCHILD SEMICONDUCTOR CORP
Description: Small Signal Bipolar Transistor, 1A I(C), 1-Element, NPN, Silicon, TO-18
Status Discontinued
Collector Current-Max (IC) (A) 1.0000000000000000
Configuration SINGLE
DC Current Gain-Min (hFE) 100.0000000000000000
JEDEC-95 Code TO-18
JESD-30 Code O-MBCY-W3
J-STD-609 Code e0
Number of Elements 1
Number of Terminals 3
Operating Temperature-Max (Cel) 175
Package Body Material METAL
Package Shape ROUND
Package Style CYLINDRICAL
Polarity/Channel Type NPN
Power Dissipation-Max (W) 0.500000000000000
DLA Qualification Not Qualified
Surface Mount NO
Terminal Finish Tin/Lead (Sn/Pb)
Terminal Form WIRE
Terminal Position BOTTOM
Application SWITCHING
Transistor Element Material SILICON
Transition Frequency-Nom (fT) (MHz) 250.0000000000000000
Turn-off Time-Max (toff) (ns) 1000.0000000000000000
