(12PCS) SN74HC245DW TI Bus Transceiver, 1-Func, 8-Bit, True Output, CMOS, SOIC20
Tax included.
This listing is for (12PCS) of SN74HC245DW by Texas Instruments
Mfr Package Description SOIC-20
REACH Compliant Yes
EU RoHS Compliant Yes
China RoHS Compliant Yes
Status Active
Logic IC Type BUS TRANSCEIVER
Control Type COMMON CONTROL
Count Direction BIDIRECTIONAL
Family HC
JESD-30 Code R-PDSO-G20
JESD-609 Code e4
Load Capacitance (CL) 150.0 pF
Max I(ol) 0.0078 Amp
Moisture Sensitivity Level 1
Number of Bits 8
Number of Functions 1
Number of Ports 2
Number of Terminals 20
Operating Temperature-Min -40.0 Cel
Operating Temperature-Max 85.0 Cel
Output Characteristics 3-STATE
Output Polarity TRUE
Package Body Material PLASTIC/EPOXY
Package Code SOP
Package Equivalence Code SOP20,.4
Package Shape RECTANGULAR
Package Style SMALL OUTLINE
Packing Method TUBE
Peak Reflow Temperature (Cel) 260
Power Supply Current-Max (ICC) 0.08 mA
Prop. Delay@Nom-Sup 22.0 ns
Propagation Delay (tpd) 170.0 ns
Qualification Status Not Qualified
Schmitt Trigger NO
Seated Height-Max 2.65 mm
Supply Voltage-Nom (Vsup) 6
Supply Voltage-Min (Vsup) 2.0 V
Supply Voltage-Max (Vsup) 6.0 V
Surface Mount YES
Technology CMOS
Temperature Grade INDUSTRIAL
Terminal Finish NICKEL PALLADIUM GOLD
Terminal Form GULL WING
Terminal Pitch 1.27 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 30
Length 12.8 mm
Width 7.5 mm
Additional Feature DIRECTION CONTROL
