(10PCS) SN74LVC1G32DBVR TI OR Gate 1-Element 2-IN CMOS 5-Pin SOT-23
Tax included.
THIS LISTING IS FOR (10PCS) OF SN74LVC1G32DBVR BY TEXAS INSTRUMENTS
SPECIFICATIONS
| Mfr Package Description | SOT-23, 5 PIN |
| REACH Compliant | Yes |
| EU RoHS Compliant | Yes |
| China RoHS Compliant | Yes |
| Status | Active |
| Logic IC Type | OR GATE |
| Sub Category | Gates |
| Family | LVC/LCX/Z |
| JESD-30 Code | R-PDSO-G5 |
| JESD-609 Code | e4 |
| Load Capacitance (CL) | 50.0 pF |
| Load/Preset Input | YES |
| Max I(ol) | 0.024 Amp |
| Moisture Sensitivity Level | 1 |
| Number of Functions | 1 |
| Number of Inputs | 2.0 |
| Number of Terminals | 5 |
| Operating Temperature-Min | -40.0 Cel |
| Operating Temperature-Max | 125.0 Cel |
| Output Characteristics | 3-STATE |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | LSSOP |
| Package Equivalence Code | TSOP5/6,.11,37 |
| Package Shape | RECTANGULAR |
| Package Style | SMALL OUTLINE, LOW PROFILE, SHRINK PITCH |
| Packing Method | TAPE AND REEL |
| Peak Reflow Temperature (Cel) | 260 |
| Power Supplies (V) | 3.3 |
| Prop. Delay@Nom-Sup | 4.5 ns |
| Propagation Delay (tpd) | 8.0 ns |
| Qualification Status | Not Qualified |
| Schmitt Trigger | NO |
| Seated Height-Max | 1.45 mm |
| Supply Voltage-Nom (Vsup) | 3.3 |
| Supply Voltage-Min (Vsup) | 1.65 V |
| Supply Voltage-Max (Vsup) | 5.5 V |
| Surface Mount | YES |
| Technology | CMOS |
| Temperature Grade | AUTOMOTIVE |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) |
| Terminal Form | GULL WING |
| Terminal Pitch | 0.95 mm |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
| Length | 2.9 mm |
| Width | 1.6 mm |
