(10PCS) PP3500SA-LF-T PROTEK THYRISTOR 60A, SILICON SURGE PROTECTOR, DO-214AA
Tax included.
THIS LISTING IS FOR (10PCS) OF PP3500SA-LF-T BY PROTEK
**WE CURRENTLY HAVE 3000PCS IN STOCK AND WILL GLADLY MAKE DEALS ON LARGER QUANTITIES. PLEASE SEND OFFERS OR INQUIRIES.
SPECIFICATIONS
| Mfr Package Description | ROHS AND REACH COMPLIANT, PLASTIC PACKAGE-2 |
| REACH Compliant | Yes |
| EU RoHS Compliant | Yes |
| Status | Active |
| Trigger Device Type | SILICON SURGE PROTECTOR |
| Configuration | SINGLE |
| DC Off-state Voltage-Max | 300 V |
| Holding Current-Max | 150 mA |
| JEDEC-95 Code | DO-214AA |
| JESD-30 Code | R-PDSO-C2 |
| JESD-609 Code | e3 |
| Non-Repetitive Pk On-state Cur | 60 A |
| Number of Elements | 1 |
| Number of Terminals | 2 |
| Operating Temperature-Min | -40 Cel |
| Operating Temperature-Max | 150 Cel |
| Package Body Material | PLASTIC/EPOXY |
| Package Shape | RECTANGULAR |
| Package Style | SMALL OUTLINE |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED |
| Qualification Status | Not Qualified |
| Sub Category | Silicon Surge Protectors |
| Surface Mount | YES |
| Terminal Form | C BEND |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED |
| Additional Feature | UL RECOGNIZED |
